Roots Blower
-
Roots blower is a positive displacement blower that delivers a constant volume of air regardless of pressure changes. It operates by trapping air between rotating lobes and transferring it from the inlet to the outlet.
Unlike centrifugal fans, the airflow of a roots blower remains stable even when system resistance fluctuates, making it ideal for industrial processes requiring continuous and reliable air supply.
-
Constant Airflow Output (Not affected by pressure fluctuations)
Oil-Free Air Delivery
Simple Structure & Easy Maintenance
High Reliability for Continuous Operation
Suitable for Low to Medium Pressure Applications
Compact Design with Stable Performance
-
The roots blower consists of:
Twin / Triple Lobed Rotors
Casing (Housing)
Timing Gears
Bearings & Shaft
-
Parameter Specification
Airflow 0.5 – 200 m³/min Pressure Range 9.8 – 98 kPa Motor Power 0.75 – 315 kW Cooling Type Air Cooling / Water Cooling Drive Type Belt Drive / Direct Coupling Material Cast Iron / Stainless Steel
